HBLV-06 Ventilated Box Lockers

More from: Lockers

Perfect for gyms and school athletic programs.

Multiple configurations help you maximize your space.

304 Stainless Steel Recessed Handle

Deep-drawn 304 stainless steel recessed handle multi-point gravity-lift type latching.

Single Point Latching

Single-point projecting friction catch door pull prepared for both padlock or built-in lock. No moving parts ensure quiet maintenance-free operation. All box door finger pulls are made of a super tough nylon material which includes an Antimicrobial agent

Diamond Perforated Ventilation

Athletic-type lockers use diamond perforated doors and sides to ensure proper ventilation.

Overview
Catalog
Components
Color
Documents

Back to top

Product Overview

Athletic All-Welded Lockers

Widths for all-welded box locker openings 12", 15", 18"
Depths for all-welded box locker openings 12", 16", 18", 22"

Note: Please note that the actual units supplied will be fabricated to meet layout and job conditions in standard width units up to 60'' wide

Body/Frame Description:

Unibody all-welded construction, 16 gauge 1-1/2" high continuous bottom with reinforcing channels welded to the underside at each side panel providing a rigid unit base. 16 gauge continuous top, 16 gauge diamond perforated sides are integral with front vertical frame, 18 gauge solid back

Body/Frame:

Unibody All-Welded

Body Styles:

Four-tier, Five-tier, Six-tier, Seven-tier, Eight-tier, Nine-tier

Doors:

14 gauge diamond perforated doors are standard. Louvered, Secure-Air-Flow and plain door styles are available.

Handle:

Single-point thru-the-door projecting finger pull handle with padlock hasp.

Handle Options:

Optional deep-drawn seamless stainless steel recessed handle is available

Hinges:

16 gauge continuous piano hinge

Hooks:

none

Coat Rods:

none

Shelves:

16 gauge intermediate shelves

Catalog

Tier	Opening Heights	Nominal Column Heights
Four Tier	12", 15", 18"	48", 60", 72"
Five Tier	12", 14.4"	60", 72"
Six Tier	8", 10", 12"	48", 60", 72"
Seven Tier	(6) 10" & (1) 12"	72"
Eight Tier	8", 9"	64", 72"
Nine Tier	8"	72"
