Premium Box KD Lockers







Features:

(Box Lockers = doors 18" high and under)

• body construction: knock-down 24 guage solid body components
• doors: 18 gauge, louvered doors are standard. plain, secure-air-flow, saftey-view plus, and diamond perforated, door styles available
• frame: 16 guage frame
• handle: projecting finger pull
• door strike: continuous virticle door strike at both hinge and latch side
• latching: single-point thru-the-door finger pull padlock hasp
• hinges: 16 guage continuous piano hinge
• hooks: none
• legs: production lockers are supplied without legs unless otherwise specified
• warranty: 2 years

Colors: choose from any of our 24 Designer Powder-Coat colors

	Premium KD Locker Sizes	Width	Depth	Opening Height	Frame Height
Wardrobe	Single Tier	9" 12" 15" 18" 24"	12" 15" 18" 21" 24"	36" 48" 60" 72"	36" 48" 60" 72"
	Double Tier	9" 12" 15" 18"	12" 15" 18" 21"	30" 36"	60" 72"
	Triple Tier	9" 12" 15" 18''	12" 15" 18" 21''	20" 24"	60" 72"
Box	Four Tier	12'', 15''	12" 15" 18"	15'', 18''	60" 72"
	Five Tier	12'', 15''	12" 15" 18"	12'', 14.4''	60" 72"
	Six Tier	12'', 15''	12" 15" 18"	12''	72"
Specialty	Two Person	15'', 18''	12" 15" 18"	N/A	60" 72"
	Duplex	15''	12" 15" 18"	60'', 72''	60" 72"
	Sixteen Person	72''	18''	12''	78'' (includes 6'' legs)
	4 Wide wall mount	48''	18"	12''	14-3/4

Photos:
